Tracer Loop Layout (FM-3L-119)
Tracer Loop Layout (FM-3L-119)
We’ve done the designing for you! Each of our Curated Layouts have been carefully crafted to work with varying ceiling areas and heights. The dimensions for this layout are as follows:
Area on Ceiling: 96in x 192in
Maximum Drop: 60in
This layout is recommended for ceiling heights of 12ft - 15ft but may work in other areas depending on site conditions. If you would like to make modifications to this layout or have any other questions, please email us at info@lukelampco.com.
The ceiling plane shown in the images is not included; each loop mounts individually to the ceiling as explained in the installation instructions below.
8-10 week leadtime.
Request Sample
Resource Library
Pictured in Satin Brass. Also available in Matte White, Blackened Brass, Antique Brass, Satin Nickel, Polished Nickel, and Satin Copper. View our finish library.
____________________________________________________
Our fixtures are low voltage (24VDC) and must be installed with the appropriate drivers, which we include. Read about our driver options here.
